Owandy I-Max 3D XPRO CBCT Unit Dental Cone Beam

Owandy I-Max 3D XPRO CBCT Unit Dental Cone Beam

Special Order: Ships in 2-4 weeks

SKU 22909001
Owandy # 9304100011, 9304301011
$48,899.99
$48,899.99
$48,899.99
Model: I-Max 3D XPRO CBCT – Wall-Mounted (# 9304100011)
FOV Option (EXT-FOV1611): W/O 16x11 cm Upgrade

Fast, secure delivery – Door-to-door service in SoCal.

Expert tech support – Installation consultation available.

30‑day money‑back guarantee – Easy returns & full refunds.

Owandy I-Max 3D XPRO is a compact wall-mounted CBCT system featuring multiple FOV options and advanced QuickVision 3D software. Available in CBCT-only and CBCT + Ceph configurations, it delivers precise imaging for implant planning and orthodontic diagnostics.

Features

  • Owandy I-Max 3D XPRO CBCT Unit: Premium 3D dental imaging system delivering 70μ ultra-high resolution for precise diagnosis, implant planning, and surgical guidance.
  • 4-in-1 Imaging System: Supports panoramic X-ray, 3D CBCT scanning, cephalometric imaging, and 3D model/object scanning in one integrated platform.
  • Compact Wall-Mounted Design: Ultra-compact footprint (<1m²) with wall-mounted installation, ideal for space-saving and efficient clinic setup.
  • Multi FOV Flexibility: 20 selectable 3D programs with adjustable field of view from 5×5 cm (single tooth) to 16×11 cm (full cranial imaging).
  • Reduced Radiation Exposure: Smart FOV targeting minimizes radiation by focusing only on the region of interest for safer patient imaging.
  • Face-to-Face Positioning: Open design allows direct patient alignment, improving positioning accuracy and scan consistency.
  • Clinical Efficiency: Streamlines diagnosis, implant planning, orthodontics, and oral surgery with fast, high-quality 3D imaging workflow.
  • Surgical Guide Support: Enables digital implant planning and surgical guide creation for improved precision and predictable outcomes.
  • Multi-Specialty Application: Suitable for implantology, orthodontics, oral surgery, and general dental diagnostics.
  • Optional Upgrade Service: 16x11 cm FOV Upgrade for Imax 3D XPRO – Optional upgrade expanding the field of view to 16x11 cm for enhanced imaging capability.

Technical Specifications

Model I-MAX  I-MAX CEPH
SKU 22909001 22909002
Part# 9304100011 9304301011
Power supply 110–120 V, 220–240 V at 50/60Hz 110–120 V, 220–240 V at 50/60Hz
Anode voltage 70 kVp ±8% 86 kVp ±8%
Anode current 7.1 mA ±10% 12.5 mA ±10%
SID (Source to Image Distance) 19.7 in / 50 cm 20.5 in / 52 cm (2D)
65.0 in / 165 cm (Ceph)
Total weight 136.7 lbs / 62 kg 264.6 lbs / 120 kg
Inherent filtration 2 mm Al eq. @ 70 kVp ≥2.5 mm Al eq. @ 86 kVp
HF generator Constant potential (DC) Constant potential (DC)
X-ray focal spot 0.5 mm EN 60336 0.5 mm EN 60336
Connection LAN, Ethernet (w/o dedicated PC) LAN Ethernet (dedicated PC)
Exposure time 2.44–14.4 s (PAN adult/child) 2.44–14.4 s (PAN adult/child)



Warranty and Installation

  • 5-year warranty: All complete units come with a 2-year warranty, and key components are covered by an additional 3-year free extended warranty.
  • Installation Services: Professional installation services are available in Southern California. Please contact our service team at service@jmudental.com for availability, service details, and pricing information.
📁 Owandy I-Max 3D XPRO Cone Beam User Manual Login To Download
